4 FRONT PANEL
4.1 FRONT PANEL
The following diagram shows the front panel of a typical 80TE unit. The hinged covers at the top and bottom
of the front panel are shown open. An optional transparent front cover physically protects the front panel.
Figure 4: Front panel (80TE)
The front panel consists of:
● Top and bottom compartments with hinged cover
● LCD display
● Keypad
● Front serial port
● Front parallel port
● Fixed function LEDs
● Function keys and LEDs
● Programmable LEDs
Note:
Due to the number of required input modules, the P747 only comes in an 80TE case
MiCOM P747 Chapter 3 - Hardware Design
P747-TM-EN-1 29
