7 MECHANICAL SPECIFICATIONS
7.1 PHYSICAL PARAMETERS
Case Types
40TE
60TE
80TE
Weight (40TE case) 7 kg – 8 kg (depending on chosen options)
Weight (60TE case) 9 kg – 12 kg (depending on chosen options)
Weight (80TE case) 13 kg - 14 kg (depending on chosen options)
Dimensions in mm (w x h x l) (40TE case) W: 206.0 mm H: 177.0 mm D: 243.1 mm
Dimensions in mm (w x h x l) (60TE case) W: 309.6 mm H: 177.0 mm D: 243.1 mm
Dimensions in mm (w x h x l) (80TE case) W 413.2 mm H 177.0 mm D 243.1 mm
Mounting Panel, rack, or retrofit
7.2 ENCLOSURE PROTECTION
Against dust and dripping water (front face) IP52 as per IEC 60529:2002
Protection against dust (whole case) IP50 as per IEC 60529:2002
Protection for sides of the case (safety) IP30 as per IEC 60529:2002
Protection for rear of the case (safety) IP10 as per IEC 60529:2002
7.3 MECHANICAL ROBUSTNESS
Mechanical Robustness
Vibration test per EN 60255-21-1:1996 Response: class 2, Endurance: class 2
Shock and bump immunity per EN 60255-21-2:1995
Shock response: class 2, Shock withstand: class 1, Bump
withstand: class 1
Seismic test per EN 60255-21-3: 1995 Class 2
7.4 TRANSIT PACKAGING PERFORMANCE
Primary packaging carton protection ISTA 1C
Vibration tests 3 orientations, 7 Hz, amplitude 5.3 mm, acceleration 1.05g
Drop tests
10 drops from 610 mm height on multiple carton faces, edges
and corners
MiCOM P747 Chapter 16 - Technical Specifications
P747-TM-EN-1 395
