1.5 CURVE TOOL
The User Programmable Curve Tool (UPCT) allows you to create user-defined curves and to download and
upload these curves to and from the IED. You can use this tool to create programmable operate and reset
curves. You can also create and visualize curves either by entering formulae or data points.
1.6 S&R COURIER
Settings and Records - Courier enables you to connect to any Courier device, retrieve and edit its settings
and send the modified settings back to a Courier device, including DNP 3.0 configuration if supported by the
device.
Although each device has different settings, each cell is presented in a uniform style, showing the
permissible range and step size allowed.
Settings and Records - Courier also enables you to:
● extract events from a device
● extract disturbance records from a device
● control breakers and isolators
● set the date and time on a device
● set the active group on a device
● change the address of a device
● save settings, DNP 3.0 configuration, events and disturbance files to disk
1.7 AEDR2
AutoExtract Disturbance Records 2 (AEDR2) automatically reads COMTRADE disturbance records from the
rear communication ports of both K-Series and MiCOM Px40 devices with the Courier protocol, and from
Px40 or Px30 devices with the IEC
60870‑5‑103 protocol.
AEDR2 is configured with an initialisation file. This file contains all settings, file names and file directories
needed for configuration. This file can be created and edited using a standard text editor. Log files are also
defined in the initialisation file which are used by AEDR2 to record a history of events and errors.
Once configured, disturbance records are automatically extracted according to a schedule from devices
connected in a defined range of addresses. This is done using the Windows® Scheduled Task facility which
can be used to execute one or several schedules. All new disturbance records are saved to a user-defined
drive and filename.
AEDR2 also has a test function to ensure the initialisation file has been properly configured. The command
line is used to execute the test function and validate the initialisation file. The command line can also be
used to manually execute the AEDR2 application on demand.
WinAEDR2 is a management facility for AEDR2. It shows the history of all previous extractions and has
shortcut buttons to launch WaveWin, Windows Explorer and the Scheduled Task facility. It can also be used
to view log files, and edit and test the initialisation file.
1.8 WINAEDR2
WinAEDR2 is a management facility for AEDR2. It shows the history of all previous extractions and has
shortcut buttons to launch WaveWin, Windows Explorer and the Scheduled Task facility. It can also be used
to view log files, and edit and test the initialisation file.
1.9 WAVEWIN
Wavewin is used for viewing and analysing waveforms from disturbance records. It can be used to determine
the sequence of events that led to a fault.
MiCOM P747 Chapter 10 - Settings Application Software
P747-TM-EN-1 299
