GE MiCOM P747 Agile User Manual

Courier Text Col Row Default Setting Available Options
Description
This setting sets the nominal DC voltage for all opto-inputs. The Custom settign allows you to set each opto-input to any
voltage value individually.
Opto Input 1 11 02 48-54V
0 = 24/27V, 1 = 30/34V, 2 = 48/54V, 3 =
110/125V or 4 = 220/250V
This cell sets the nominal voltage for opto-input 1
Opto Input 2 11 03 48-54V
0 = 24/27V, 1 = 30/34V, 2 = 48/54V, 3 =
110/125V or 4 = 220/250V
This cell sets the nominal voltage for opto-input 2
Opto Input 3 11 04 48-54V
0 = 24/27V, 1 = 30/34V, 2 = 48/54V, 3 =
110/125V or 4 = 220/250V
This cell sets the nominal voltage for opto-input 3
Opto Input 4 11 05 48-54V
0 = 24/27V, 1 = 30/34V, 2 = 48/54V, 3 =
110/125V or 4 = 220/250V
This cell sets the nominal voltage for opto-input 4
Opto Input 5 11 06 48-54V
0 = 24/27V, 1 = 30/34V, 2 = 48/54V, 3 =
110/125V or 4 = 220/250V
This cell sets the nominal voltage for opto-input 5
Opto Input 6 11 07 48-54V
0 = 24/27V, 1 = 30/34V, 2 = 48/54V, 3 =
110/125V or 4 = 220/250V
This cell sets the nominal voltage for opto-input 6
Opto Input 7 11 08 48-54V
0 = 24/27V, 1 = 30/34V, 2 = 48/54V, 3 =
110/125V or 4 = 220/250V
This cell sets the nominal voltage for opto-input 7
Opto Input 8 11 09 48-54V
0 = 24/27V, 1 = 30/34V, 2 = 48/54V, 3 =
110/125V or 4 = 220/250V
This cell sets the nominal voltage for opto-input 8
Opto Input 9 11 0A 48-54V
0 = 24/27V, 1 = 30/34V, 2 = 48/54V, 3 =
110/125V or 4 = 220/250V
This cell sets the nominal voltage for opto-input 9
Opto Input 10 11 0B 48-54V
0 = 24/27V, 1 = 30/34V, 2 = 48/54V, 3 =
110/125V or 4 = 220/250V
This cell sets the nominal voltage for opto-input 10
Opto Input 11 11 0C 48-54V
0 = 24/27V, 1 = 30/34V, 2 = 48/54V, 3 =
110/125V or 4 = 220/250V
This cell sets the nominal voltage for opto-input 11
Opto Input 12 11 0D 48-54V
0 = 24/27V, 1 = 30/34V, 2 = 48/54V, 3 =
110/125V or 4 = 220/250V
This cell sets the nominal voltage for opto-input 12
Opto Input 13 11 0E 48-54V
0 = 24/27V, 1 = 30/34V, 2 = 48/54V, 3 =
110/125V or 4 = 220/250V
This cell sets the nominal voltage for opto-input 13
Opto Input 14 11 0F 48-54V
0 = 24/27V, 1 = 30/34V, 2 = 48/54V, 3 =
110/125V or 4 = 220/250V
This cell sets the nominal voltage for opto-input 14
Opto Input 15 11 10 48-54V
0 = 24/27V, 1 = 30/34V, 2 = 48/54V, 3 =
110/125V or 4 = 220/250V
This cell sets the nominal voltage for opto-input 15
MiCOM P747 Chapter 6 - Monitoring and Control
P747-TM-EN-1 173
P747-TM-EN-1.1
