Courier Text Col Row Default Setting Available Options
Description
Z1 CT Dir. 30 34 000000000001000011
0x00000001 Terminal 1
0x00000002 Terminal 2
0x00000004 Terminal 3
0x00000008 Terminal 4
0x00000010 Terminal 5
0x00000020 Terminal 6
0x00000040 Terminal 7
0x00000080 Terminal 8
0x00000100 Terminal 9
0x00000200 Terminal 10
0x00000400 Terminal 11
0x00000800 Terminal 12
0x00001000 Terminal 13
0x00002000 Terminal 14
0x00004000 Terminal 15
0x00008000 Terminal 16
0x00010000 Terminal 17
0x00020000 Terminal 18
This defines the CT connected to Zone 1 (normal polarity).
Z1 CT. Inv Dir 30 35 000000000000000000
0x00000001 Terminal 1
0x00000002 Terminal 2
0x00000004 Terminal 3
0x00000008 Terminal 4
0x00000010 Terminal 5
0x00000020 Terminal 6
0x00000040 Terminal 7
0x00000080 Terminal 8
0x00000100 Terminal 9
0x00000200 Terminal 10
0x00000400 Terminal 11
0x00000800 Terminal 12
0x00001000 Terminal 13
0x00002000 Terminal 14
0x00004000 Terminal 15
0x00008000 Terminal 16
0x00010000 Terminal 17
0x00020000 Terminal 18
This defines the CT connected to Zone 1 (inverse polarity).
Z2 CT Dir. 30 36 0x000000000000000011
0x00000001 Terminal 1
0x00000002 Terminal 2
0x00000004 Terminal 3
0x00000008 Terminal 4
0x00000010 Terminal 5
0x00000020 Terminal 6
0x00000040 Terminal 7
0x00000080 Terminal 8
0x00000100 Terminal 9
0x00000200 Terminal 10
0x00000400 Terminal 11
0x00000800 Terminal 12
0x00001000 Terminal 13
0x00002000 Terminal 14
0x00004000 Terminal 15
0x00008000 Terminal 16
0x00010000 Terminal 17
0x00020000 Terminal 18
This defines the CT connected to Zone 2 (normal polarity).
MiCOM P747 Chapter 4 - Configuration
P747-TM-EN-1 91
P747-TM-EN-1.1
