Courier Text Col Row Default Setting Available Options
Description
Sets the phase Current Transformer input secondary current rating
Terminal 11 CT 0A 38
This sets CT main data
Polarity 0A 39 Standard 0 = Standard or 1 = Inverted
Standard or reverse phase sequence can be selected. This menu sets this phase
sequence.
Primary 0A 3A 1000 From to step
Sets the phase Current Transformer input primary current rating
Secondary 0A 3B 1 From to step
Sets the phase Current Transformer input secondary current rating
Terminal 12 CT 0A 3C
This sets CT main data
Polarity 0A 3D Standard 0 = Standard or 1 = Inverted
Standard or reverse phase sequence can be selected. This menu sets this phase
sequence.
Primary 0A 3E 1000 From to step
Sets the phase Current Transformer input primary current rating
Secondary 0A 3F 1 From to step
Sets the phase Current Transformer input secondary current rating
Terminal 13 CT 0A 40
This sets CT main data
Polarity 0A 41 Standard 0 = Standard or 1 = Inverted
Standard or reverse phase sequence can be selected. This menu sets this phase
sequence.
Primary 0A 42 1000 From to step
Sets the phase Current Transformer input primary current rating
Secondary 0A 43 1 From to step
Sets the phase Current Transformer input secondary current rating
Terminal 14 CT 0A 44
This sets CT main data
Polarity 0A 45 Standard 0 = Standard or 1 = Inverted
Standard or reverse phase sequence can be selected. This menu sets this phase
sequence.
Primary 0A 46 1000 From to step
Sets the phase Current Transformer input primary current rating
Secondary 0A 47 1 From to step
Sets the phase Current Transformer input secondary current rating
Terminal 15 CT 0A 48
This sets CT main data
Polarity 0A 49 Standard 0 = Standard or 1 = Inverted
Standard or reverse phase sequence can be selected. This menu sets this phase
sequence.
Primary 0A 4A 1000 From to step
Sets the phase Current Transformer input primary current rating
MiCOM P747 Chapter 4 - Configuration
P747-TM-EN-1 89
