Courier Text Col Row Default Setting Available Options
Description
Terminal 6 CT 0A 24
This sets CT main data
Polarity 0A 25 Standard 0 = Standard or 1 = Inverted
Standard or reverse phase sequence can be selected. This menu sets this phase
sequence.
Primary 0A 26 1000 From to step
Sets the phase Current Transformer input primary current rating
Secondary 0A 27 1 From to step
Sets the phase Current Transformer input secondary current rating
Terminal 7 CT 0A 28
This sets CT main data
Polarity 0A 29 Standard 0 = Standard or 1 = Inverted
Standard or reverse phase sequence can be selected. This menu sets this phase
sequence.
Primary 0A 2A 1000 From to step
Sets the phase Current Transformer input primary current rating
Secondary 0A 2B 1 From to step
Sets the phase Current Transformer input secondary current rating
Terminal 8 CT 0A 2C
This sets CT main data
Polarity 0A 2D Standard 0 = Standard or 1 = Inverted
Standard or reverse phase sequence can be selected. This menu sets this phase
sequence.
Primary 0A 2E 1000 From to step
Sets the phase Current Transformer input primary current rating
Secondary 0A 2F 1 From to step
Sets the phase Current Transformer input secondary current rating
Terminal 9 CT 0A 30
This sets CT main data
Polarity 0A 31 Standard 0 = Standard or 1 = Inverted
Standard or reverse phase sequence can be selected. This menu sets this phase
sequence.
Primary 0A 32 1000 From to step
Sets the phase Current Transformer input primary current rating
Secondary 0A 33 1 From to step
Sets the phase Current Transformer input secondary current rating
Terminal 10 CT 0A 34
This sets CT main data
Polarity 0A 35 Standard 0 = Standard or 1 = Inverted
Standard or reverse phase sequence can be selected. This menu sets this phase
sequence.
Primary 0A 36 1000 From to step
Sets the phase Current Transformer input primary current rating
Secondary 0A 37 1 From to step
Chapter 4 - Configuration MiCOM P747
88 P747-TM-EN-1
