Courier Text Col Row Default Setting Available Options
Description
This sets CT main data
Polarity 0A 11 Standard 0 = Standard or 1 = Inverted
Standard or reverse phase sequence can be selected. This menu sets this phase
sequence.
Primary 0A 12 1000 From to step
Sets the phase Current Transformer input primary current rating
Secondary 0A 13 1 From to step
Sets the phase Current Transformer input secondary current rating
Terminal 2 CT 0A 14
This sets CT main data
Polarity 0A 15 Standard 0 = Standard or 1 = Inverted
Standard or reverse phase sequence can be selected. This menu sets this phase
sequence.
Primary 0A 16 1000 From to step
Sets the phase Current Transformer input primary current rating
Secondary 0A 17 1 From to step
Sets the phase Current Transformer input secondary current rating
Terminal 3 CT 0A 18
This sets CT main data
Polarity 0A 19 Standard 0 = Standard or 1 = Inverted
Standard or reverse phase sequence can be selected. This menu sets this phase
sequence.
Primary 0A 1A 1000 From to step
Sets the phase Current Transformer input primary current rating
Secondary 0A 1B 1 From to step
Sets the phase Current Transformer input secondary current rating
Terminal 4 CT 0A 1C
This sets CT main data
Polarity 0A 1D Standard 0 = Standard or 1 = Inverted
Standard or reverse phase sequence can be selected. This menu sets this phase
sequence.
Primary 0A 1E 1000 From to step
Sets the phase Current Transformer input primary current rating
Secondary 0A 1F 1 From to step
Sets the phase Current Transformer input secondary current rating
Terminal 5 CT 0A 20
This sets CT main data
Polarity 0A 21 Standard 0 = Standard or 1 = Inverted
Standard or reverse phase sequence can be selected. This menu sets this phase
sequence.
Primary 0A 22 1000 From to step
Sets the phase Current Transformer input primary current rating
Secondary 0A 23 1 From to step
Sets the phase Current Transformer input secondary current rating
