Courier Text Col Row Default Setting Available Options
Description
Setting Group 09 02 Menu
0 = Select via Menu or 1 = Select via
PSL
This setting allows you to choose whether the setting group changes are to be initiated via an Opto-input or the HMI
menu.
Active Settings 09 03 1
0 = Group 1, 1 = Group 2, 2 = Group
3, 3 = Group 4
This setting selects the active settings group.
Save Changes 09 04 No Operation
0 = No Operation, 1 = Save, 2 =
Abort
This command saves all IED settings.
Copy From 09 05 Group 1
0 = Group 1, 1 = Group 2, 2 = Group
3, 3 = Group 4
This setting copies settings from a selected setting group.
Copy To 09 06 No Operation
0 = No Operation, 1 = Group 1, 2 =
Group 2, 3 = Group 3
This command allows the displayed settings to be copied to a selected setting group.
Setting Group 1 09 07 Enabled 0 = Disabled or 1 = Enabled
This setting enables or disables settings Group 1.
Setting Group 2 09 08 Disabled 0 = Disabled or 1 = Enabled
This setting enables or disables settings Group 2.
Setting Group 3 09 09 Disabled 0 = Disabled or 1 = Enabled
This setting enables or disables settings Group 3.
Setting Group 4 09 0A Disabled 0 = Disabled or 1 = Enabled
This setting enables or disables settings Group 4.
Diff Protection 09 0C Enabled 0 = Disabled or 1 = Enabled
This setting enables or disables differential current protection
Dead Zone OC 09 0D Disabled 0 = Disabled or 1 = Enabled
This setting enables or disables dead zone overcurrent protection
Over Current 09 10 Disabled 0 = Disabled or 1 = Enabled
This setting enables or disables overcurrent protection
CB Fail 09 20 Enabled 0 = Disabled or 1 = Enabled
This setting enables or disables the Circuit Breaker Fail Protection function.
Supervision 09 21 Disabled 0 = Disabled or 1 = Enabled
This setting enables or disables the Supervision (VTS & CTS) functions.
Input Labels 09 25 Visible 0 = Invisble or 1 = Visible
This setting hides or unhides the Input Labels menu from the IED display.
Output Labels 09 26 Visible 0 = Invisble or 1 = Visible
This setting hides or unhides the Output Labels menu from the IED display.
CT and VT Ratios 09 28 Visible 0 = Invisble or 1 = Visible
This setting hides or unhides the Current and Voltage Transformer ratios menu from the IED display.
Record Control 09 29 Visible 0 = Invisble or 1 = Visible
This setting hides or unhides the Record Control menu from the IED display.
Disturb Recorder 09 2A Visible 0 = Invisble or 1 = Visible
This setting hides or unhides the Disturbance Recorder menu from the IED display.
