GE MiCOM P747 Agile User Manual

Alarm Status 2
Bit no. Bit Mask (hex) Alarm Description
0 0x00000001 Not Used
1 0x00000002 Not Used
2 0x00000004 Setting Group selection by DDB inputs invalid
3 0x00000008 CB Status Alarm
4 0x00000010 OOS Alarm
5 0x00000020 Frequency out of range Alarm
6 0x00000040 Circuitry Fault CZ Alarm
7 0x00000080 Circuitry Fault Z1 Alarm
8 0x00000100 Circuitry Fault Z2 Alarm
9 0x00000200 Circuitry Fault Z3 Alarm
10 0x00000400 Circuitry Fault Z4 Alarm
11 0x00000800 Z1 in Diff Block Mode Alarm
12 0x00001000 Z2 in Diff Block Mode Alarm
13 0x00002000 Z3 in Diff Block Mode Alarm
14 0x00004000 Z4 in Diff Block Mode Alarm
15 0x00008000 Z1 in Diff & CBF Block Mode Alarm
16 0x00010000 Z2 in Diff & CBF Block Mode Alarm
17 0x00020000 Z3 in Diff & CBF Block Mode Alarm
18 0x00040000 Z4 in Diff & CBF Block Mode Alarm
19 0x00080000 T1 in Maintenance Mode Alarm
20 0x00100000 T2 in Maintenance Mode Alarm
21 0x00200000 T3 in Maintenance Mode Alarm
22 0x00400000 T4 in Maintenance Mode Alarm
23 0x00800000 T5 in Maintenance Mode Alarm
24 0x01000000 T6 in Maintenance Mode Alarm
25 0x02000000 T7 in Maintenance Mode Alarm
26 0x04000000 T8 in Maintenance Mode Alarm
27 0x08000000 T9 in Maintenance Mode Alarm
28 0x10000000 T10 in Maintenance Mode Alarm
29 0x20000000 T11 in Maintenance Mode Alarm
30 0x40000000 T12 in Maintenance Mode Alarm
31 0x80000000 T13 in Maintenance Mode Alarm
Alarm Status 3
Bit no.
Bit Mask (hex) Alarm Description
0 0x00000001 T14 in Maintenance Mode Alarm
1 0x00000002 T15 in Maintenance Mode Alarm
2 0x00000004 T16 in Maintenance Mode Alarm
3 0x00000008 T17 in Maintenance Mode Alarm
4 0x00000010 T18 in Maintenance Mode Alarm
5 0x00000020 Breaker Fail Any Trip
6 0x00000040 CB Fail Alarm T1
MiCOM P747 Chapter 6 - Monitoring and Control
P747-TM-EN-1 153
P747-TM-EN-1.1
