GE MiCOM P747 Agile User Manual

Courier Text Col Row Default Setting Available Options
Description
IX-12 Phase Angle 02 3C Not Settable
IX-12 Phase Angle
IX-13 Magnitude 02 3D Not Settable
IX-13 Magnitude
IX-13 Phase Angle 02 3E Not Settable
IX-13 Phase Angle
IX-14 Magnitude 02 3F Not Settable
IX-14 Magnitude
IX-14 Phase Angle 02 40 Not Settable
IX-14 Phase Angle
IX-15 Magnitude 02 41 Not Settable
IX-15 Magnitude
IX-15 Phase Angle 02 42 Not Settable
IX-15 Phase Angle
IX-16 Magnitude 02 43 Not Settable
IX-16 Magnitude
IX-16 Phase Angle 02 44 Not Settable
IX-16 Phase Angle
IX-17 Magnitude 02 45 Not Settable
IX-17 Magnitude
IX-17 Phase Angle 02 46 Not Settable
IX-17 Phase Angle
IX-18 Magnitude 02 47 Not Settable
IX-18 Magnitude
IX-18 Phase Angle 02 48 Not Settable
IX-18 Phase Angle
VxN Magnitude Z1 02 8F Not Settable
VxN Magnitude Z1
VxN Phase Angle
Z1
02 90 Not Settable
VxN Phase Angle Z1
VxN Magnitude Z2 02 91 Not Settable
VxN Magnitude Z2
VxN Phase Angle
Z2
02 92 Not Settable
VxN Phase Angle Z2
VxN Magnitude Z3 02 93 Not Settable
VxN Magnitude Z3
VxN Phase Angle
Z3
02 94 Not Settable
VxN Phase Angle Z3
VxN Magnitude Z4 02 9A Not Settable
VxN Magnitude Z4
Chapter 6 - Monitoring and Control MiCOM P747
166 P747-TM-EN-1
P747-TM-EN-1.1
