GE MiCOM P747 Agile User Manual

Courier Text Col Row Default Setting Available Options
Description
Switch Conf.Bank 19 05 No Action 0 = No Action or 1 = Switch banks
This command allows you to switch between the current configuration, held in the Active Memory Bank to the
configuration held in the Inactive Memory Bank.
Restore MCL 19 0A No Action (0) 0 = No Action or 1 = Restore MCL
This command lets you restore the MCL (MiCOM Control Language).
Active Conf.Name 19 10 Not Available Not Settable
This cell displays the name of the configuration in the Active Memory Bank (usually taken from the SCL file).
Active Conf.Rev 19 11 Not Available Not Settable
This cell displays the configuration revision number of the configuration in the Active Memory Bank (usually taken from
the SCL file).
Inact.Conf.Name 19 20 Not Available Not Settable
This cell displays the name of the configuration in the Inactive Memory Bank (usually taken from the SCL file).
Inact.Conf.Rev 19 21 Not Available Not Settable
This cell displays the configuration revision number of the configuration in the Inactive Memory Bank (usually taken from
the SCL file).
IP PARAMETERS 19 30
The data in this sub-heading relates to the IEC61850 IP parameters
IP Address 19 31 0.0.0.0 Not Settable
This cell displays the IED's IP address.
Subnet Address 19 32 0.0.0.0 Not Settable
Ths cell displays the subnet mask, which defines the subnet on which the IED is located.
Gateway 19 33 0.0.0.0 Not Settable
Ths cell displays the gateway address of the LAN on which the IED is located.
SNTP PARAMETERS 19 40
The data and settings under this sub-heading relate to the IEC61850 SNTP parameters
SNTP Server 1 19 41 0.0.0.0 Not Settable
This cell displays the IP address of the primary SNTP server.
SNTP Server 2 19 42 0.0.0.0 Not Settable
This cell displays the IP address of the secondary SNTP server.
IEC 61850 SCL 19 50
IEC61850 versions only.
IED Name 19 51 Not Available Not Settable
This setting displays the unique IED name used on the IEC 61850 network (usually taken from the SCL file).
IEC 61850 GOOSE 19 60
IEC61850 versions only.
GoEna 19 70 00000000(bin)
Bit 0=gcb01 GoEna
Bit 1=gcb02 GoEna
Bit 2=gcb03 GoEna
Bit 3=gcb04 GoEna
Bit 4=gcb05 GoEna
Bit 5=gcb06 GoEna
Bit 6=gcb07 GoEna
Bit 7=gcb08 GoEna
This setting enables the GOOSE publisher settings.
Test Mode 19 71 00000000(bin)
0 = Disabled, 1 = Pass Through, 2 =
Forced
MiCOM P747 Chapter 7 - SCADA Communications
P747-TM-EN-1 227
P747-TM-EN-1.1
