18 Nov 2002
08:59:32.047
Grp(n) PSL ID: This cell displays a unique ID number for the downloaded PSL scheme.
Example:
Grp. 1 PSL
ID - 2062813232
The complete Settings table is shown below:
Menu Text Col Row Default Setting Available Options
Description
PSL DATA B7 00
This column contains information about the Programmable Scheme Logic
Grp1 PSL Ref B7 01 Not settable
This setting displays the Group 1 PSL reference
Date/Time B7 02 Not settable
This setting displays the date and time the PSL was created
Grp1 PSL ID B7 03 Not settable
This setting displays the Group 1 PSL ID
Grp2 PSL Ref B7 11 Not settable
This setting displays the Group 2 PSL reference
Date/Time B7 12 Not settable
This setting displays the date and time the PSL was created
Grp2 PSL ID B7 13 Not settable
This setting displays the Group 2 PSL ID
Grp3 PSL Ref B7 21 Not settable
This setting displays the Group 3 PSL reference
Date/Time B7 22 Not settable
This setting displays the date and time the PSL was created
Grp3 PSL ID B7 23 Not settable
This setting displays the Group 3 PSL ID
Grp4 PSL Ref B7 31 Not settable
This setting displays the Group 4 PSL reference
Date/Time B7 32 Not settable
This setting displays the date and time the PSL was created
Grp4 PSL ID B7 33 Not settable
This setting displays the Group 4 PSL ID
MiCOM P747 Chapter 12 - Scheme Logic
P747-TM-EN-1 327
