GE Multilin F650 Digital Bay Controller B-51

APPENDIX B B.1 MODBUS PROTOCOL FOR 650

ADDRESS Bit Name Format Step Mode Length Miscellaneous

Funciones Protección habilitadas - Protection Summary (cont.)

0x24A1 0x0001 Sensitive Ground TOC1 F001 R 1

0x24BD 0x0001 Sensitive Ground TOC2 F001 R 1

0x24D9 0x0001 Sensitive Ground TOC3 F001 R 1

0x24F5 0x0001 Phase UV1 F001 R 1

0x2514 0x0001 Phase UV2 F001 R 1

0x2533 0x0001 Phase UV3 F001 R 1

0x2552 0x0001 Negative Sequence OV1 F001 R 1

0x256D 0x0001 Negative Sequence OV2 F001 R 1

0x2588 0x0001 Negative Sequence OV3 F001 R 1

0x25A3 0x0001 Thermal Model1 F001 R 1

0x25C0 0x0001 Thermal Model2 F001 R 1

0x25DD 0x0001 Thermal Model3 F001 R 1

0x25FA 0x0001 Phase Directional1 F001 R 1

0x2615 0x0001 Phase Directional2 F001 R 1

0x2630 0x0001 Phase Directional3 F001 R 1

0x264B 0x0001 Neutral Directional1 F001 R 1

0x2667 0x0001 Neutral Directional2 F001 R 1

0x2683 0x0001 Neutral Directional3 F001 R 1

0x269F 0x0001 Ground Directional1 F001 R 1

0x26BB 0x0001 Ground Directional2 F001 R 1

0x26D7 0x0001 Ground Directional3 F001 R 1

0x26F3 0x0001 Breaker Failure F001 R 1

0x271C 0x0001 Fuse Failure F001 R 1

0x2731 0x0001 Synchrocheck F001 R 1

0x2763 0x0001 Recloser F001 R 1

0x278C 0x0001 Neutral OV1 High F001 R 1

0x27A7 0x0001 Neutral OV2 High F001 R 1

0x27C2 0x0001 Neutral OV3 High F001 R 1

0x27DD 0x0001 Neutral OV1 Low F001 R 1

0x27F8 0x0001 Neutral OV2 Low F001 R 1

0x2813 0x0001 Neutral OV3 Low F001 R 1

0x282E 0x0001 Auxiliary UV1 F001 R 1

0x2848 0x0001 Auxiliary UV2 F001 R 1

0x2862 0x0001 Auxiliary UV3 F001 R 1

0x287C 0x0001 Phase OV1 F001 R 1

0x2898 0x0001 Phase OV2 F001 R 1

0x28B4 0x0001 Phase OV3 F001 R 1

0x28D0 0x0001 Auxiliary OV1 F001 R 1

0x28EB 0x0001 Auxiliary OV2 F001 R 1

0x2906 0x0001 Auxiliary OV3 F001 R 1

0x2921 0x0001 I2 TOC1 F001 R 1

0x293C 0x0001 I2 TOC2 F001 R 1

0x2957 0x0001 I2 TOC3 F001 R 1

0x2972 0x0001 Overfrequency1 F001 R 1

0x298F 0x0001 Overfrequency2 F001 R 1

0x29AC 0x0001 Overfrequency3 F001 R 1
