B-52 F650 Digital Bay Controller GE Multilin

B.1 MODBUS PROTOCOL FOR 650 APPENDIX B

ADDRESS Bit Name Format Step Mode Length Miscellaneous

Funciones Protección habilitadas - Protection Summary (cont.)

0x24A1 0x0001 Sensitive Ground TOC1 F001 R 1

0x29C9 0x0001 Underfrequency1 F001 R 1

0x29E6 0x0001 Underfrequency2 F001 R 1

0x2A03 0x0001 Underfrequency3 F001 R 1

0x2A7C 0x0001 Oscillography F001 R 1

0x2A93 0x0001 Fault Report F001 R 1

0x2C08 0x0001 Broken Conductor1 F001 R 1

0x2C21 0x0001 Broken Conductor2 F001 R 1

0x2C3A 0x0001 Broken Conductor3 F001 R 1

0x2DF6 0x0001 Isolated Ground IOC1 F001 R 1

0x2E17 0x0001 Isolated Ground IOC2 F001 R 1

0x2E38 0x0001 Isolated Ground IOC3 F001 R 1

0x2E59 0x0001 Sensitive Ground Directional1 F001 R 1

0x2E74 0x0001 Sensitive Ground Directional2 F001 R 1

0x2E8F 0x0001 Sensitive Ground Directional3 F001 R 1

0x2EAA 0x0001 Forward power1 F001 R 1

0x2EC9 0x0001 Forward power2 F001 R 1

0x2EE8 0x0001 Forward power3 F001 R 1

0x2F07 0x0001 Demand F001 R 1

0x2F20 0x0001 IEC104 Protocol F001 R 1

0x32A5 0x0001 Phase TOC1 Low F001 R 1

0x32C2 0x0001 Phase TOC2 Low F001 R 1

0x32DF 0x0001 Phase TOC3 Low F001 R 1

0x38D4 0x0001 Data Logger F001 R 1

0x38FA 0x0001 Directional Power1 F001 R 1

0x391D 0x0001 Directional Power2 F001 R 1

0x3940 0x0001 Directional Power3 F001 R 1

0x3963 0x0001 Locked Rotor1 F001 R 1

0x3978 0x0001 Locked Rotor2 F001 R 1

0x398D 0x0001 Locked Rotor3 F001 R 1

Funciones con Eventos habilitados - Snapshot Events Summary

0x1EE5 0x0001 Board F Event F001 R 1

0x208A 0x0001 Board G Event F001 R 1

0x2199 0x0001 General Settings Event F001 R 1

0x220C 0x0001 Phase IOC1 High Event F001 R 1

0x2228 0x0001 Phase IOC2 High Event F001 R 1

0x2244 0x0001 Phase IOC3 High Event F001 R 1

0x2260 0x0001 Phase IOC1 Low Event F001 R 1

0x227C 0x0001 Phase IOC2 Low Event F001 R 1

0x2298 0x0001 Phase IOC3 Low Event F001 R 1

0x22B3 0x0001 Neutral IOC1 Event F001 R 1

0x22CE 0x0001 Neutral IOC2 Event F001 R 1

0x22E9 0x0001 Neutral IOC3 Event F001 R 1

0x2305 0x0001 Ground IOC1 Event F001 R 1

0x2321 0x0001 Ground IOC2 Event F001 R 1

0x233D 0x0001 Ground IOC3 Event F001 R 1
