GE Multilin F650 Digital Bay Controller B-53

APPENDIX B B.1 MODBUS PROTOCOL FOR 650

ADDRESS Bit Name Format Step Mode Length Miscellaneous

Funciones con Eventos habilitados - Snapshot Events Summary (cont.)

0x2359 0x0001 Sensitive Ground IOC1 Event F001 R 1

0x2375 0x0001 Sensitive Ground IOC2 Event F001 R 1

0x2391 0x0001 Sensitive Ground IOC3 Event F001 R 1

0x23AE 0x0001 Phase TOC1 High Event F001 R 1

0x23CB 0x0001 Phase TOC2 High Event F001 R 1

0x23E8 0x0001 Phase TOC3 High Event F001 R 1

0x2403 0x0001 Neutral TOC1 Event F001 R 1

0x241E 0x0001 Neutral TOC2 Event F001 R 1

0x2439 0x0001 Neutral TOC3 Event F001 R 1

0x2455 0x0001 Ground TOC1 Event F001 R 1

0x2471 0x0001 Ground TOC2 Event F001 R 1

0x248D 0x0001 Ground TOC3 Event F001 R 1

0x24A9 0x0001 Sensitive Ground TOC1 Event F001 R 1

0x24C5 0x0001 Sensitive Ground TOC2 Event F001 R 1

0x24E1 0x0001 Sensitive Ground TOC3 Event F001 R 1

0x2500 0x0001 Phase UV1 Event F001 R 1

0x251F 0x0001 Phase UV2 Event F001 R 1

0x253E 0x0001 Phase UV3 Event F001 R 1

0x2559 0x0001 Negative Sequence OV1 Event F001 R 1

0x2574 0x0001 Negative Sequence OV2 Event F001 R 1

0x258F 0x0001 Negative Sequence OV3 Event F001 R 1

0x25AC 0x0001 Thermal Model1 Event F001 R 1

0x25C9 0x0001 Thermal Model2 Event F001 R 1

0x25E6 0x0001 Thermal Model3 Event F001 R 1

0x2601 0x0001 Phase Directional1 Event F001 R 1

0x261C 0x0001 Phase Directional2 Event F001 R 1

0x2637 0x0001 Phase Directional3 Event F001 R 1

0x2653 0x0001 Neutral Directional1 Event F001 R 1

0x266F 0x0001 Neutral Directional2 Event F001 R 1

0x268B 0x0001 Neutral Directional3 Event F001 R 1

0x26A7 0x0001 Ground Directional1 Event F001 R 1

0x26C3 0x0001 Ground Directional2 Event F001 R 1

0x26DF 0x0001 Ground Directional3 Event F001 R 1

0x2708 0x0001 Breaker Failure Event F001 R 1

0x271D 0x0001 Fuse Failure Event F001 R 1

0x2745 0x0001 Synchrocheck Event F001 R 1

0x2774 0x0001 Recloser Event F001 R 1

0x2793 0x0001 Neutral OV1 High Event F001 R 1

0x27AE 0x0001 Neutral OV2 High Event F001 R 1

0x27C9 0x0001 Neutral OV3 High Event F001 R 1

0x27E4 0x0001 Neutral OV1 Low Event F001 R 1

0x27FF 0x0001 Neutral OV2 Low Event F001 R 1

0x281A 0x0001 Neutral OV3 Low Event F001 R 1

0x2834 0x0001 Auxiliary UV1 Event F001 R 1

0x284E 0x0001 Auxiliary UV2 Event F001 R 1

0x2868 0x0001 Auxiliary UV3 Event F001 R 1
