B-54 F650 Digital Bay Controller GE Multilin

B.1 MODBUS PROTOCOL FOR 650 APPENDIX B

ADDRESS Bit Name Format Step Mode Length Miscellaneous

Funciones con Eventos habilitados - Snapshot Events Summary (cont.)

0x2884 0x0001 Phase OV1 Event F001 R 1

0x28A0 0x0001 Phase OV2 Event F001 R 1

0x28BC 0x0001 Phase OV3 Event F001 R 1

0x28D7 0x0001 Auxiliary OV1 Event F001 R 1

0x28F2 0x0001 Auxiliary OV2 Event F001 R 1

0x290D 0x0001 Auxiliary OV3 Event F001 R 1

0x2928 0x0001 Negative Sequence TOC1 Event F001 R 1

0x2943 0x0001 Negative Sequence TOC2 Event F001 R 1

0x295E 0x0001 Negative Sequence TOC3 Event F001 R 1

0x297B 0x0001 Overfrequency1 Event F001 R 1

0x2998 0x0001 Overfrequency2 Event F001 R 1

0x29B5 0x0001 Overfrequency3 Event F001 R 1

0x29D2 0x0001 Underfrequency1 Event F001 R 1

0x29EF 0x0001 Underfrequency2 Event F001 R 1

0x2A0C 0x0001 Underfrequency3 Event F001 R 1

0x2A81 0x0001 Oscillography Event F001 R 1

0x2A9F 0x0001 Fault Report Event F001 R 1

0x2C0D 0x0001 Broken Conductor1 Event F001 R 1

0x2C26 0x0001 Broken Conductor2 Event F001 R 1

0x2C3F 0x0001 Broken Conductor3 Event F001 R 1

0x2E03 0x0001 Isolated Ground IOC1 Event F001 R 1

0x2E24 0x0001 Isolated Ground IOC2 Event F001 R 1

0x2E45 0x0001 Isolated Ground IOC3 Event F001 R 1

0x2E60 0x0001 Sensitive Ground Directional1 Event F001 R 1

0x2E7B 0x0001 Sensitive Ground Directional2 Event F001 R 1

0x2E96 0x0001 Sensitive Ground Directional3 Event F001 R 1

0x2EB5 0x0001 Forward Power1 Event F001 R 1

0x2ED4 0x0001 Forward Power2 Event F001 R 1

0x2EF3 0x0001 Forward Power3 Event F001 R 1

0x2F0C 0x0001 Demand Event F001 R 1

0x32AE 0x0001 Phase TOC1 Low Event F001 R 1

0x32CB 0x0001 Phase TOC2 Low Event F001 R 1

0x32E8 0x0001 Phase TOC3 Low Event F001 R 1

0x3909 0x0001 Directional Power1 Event F001 R 1

0x392C 0x0001 Directional Power2 Event F001 R 1

0x394F 0x0001 Directional Power3 Event F001 R 1

0x396D 0x0001 Locked Rotor1 Event F001 R 1

0x3982 0x0001 Locked Rotor2 Event F001 R 1

0x3997 0x0001 Locked Rotor3 Event F001 R 1

Mapa de Usuario - User Map

0xF330 Address 00 F004 1 R 1

0xF331 Address 01 F004 1 R 1

... ... ... ... ... ... ... ...

0xF42F Address 255 F004 1 R 1
