IRECTION FR091521, REVISION 1VIVID S60N/VIVID S70N BASIC SERVICE MANUAL
Chapter 4 - General Procedures and Functional Checks 4-35
PRELIMINARY
4-3-9 ECG Check
4-3-9-1 Introduction
The ECG capability on this unit, is intended as use as a trigger for measurements, but can also be
viewed on the screen.
4-3-9-2 Parts Needed
• ECG Harness, P/N:16L0026 + P/N:16L0028
• ECG Pads, (3 pc)
or
• ECG simulator
4-3-9-3 Preparations
None
4-3-9-4 ECG Check
Table 4-3 ECG Checks
Step Task Expected Result(s)
1
Connect the ECG harness to the
connector on the front of the
system.
The unit displays a straight curve along
the bottom edge of the image sector on
the screen.
2
Connect the three leads to an
ECG simulator,
or:
Fasten the three ECG Pads to
your body and connect the three
leads to respective ECG Pad.
When connecting, the signal on the
screen will be noisy.
When the connection is completed, a
typical clean ECG signal is displayed.
To Next Page
