IRECTION FR091521, REVISION 1 VIVID S60N/VIVID S70N BASIC SERVICE MANUAL
8-72 Section 8-4 - Cables - Replacement Procedures
PRELIMINARY
8-4-1-5 Keyboard and Monitor Cable Installation Procedure
When replacing the cables refer to the context graphic shown in Figure 8-91 below.
NOTE: The following stages show the order in which cables are installed:
LCD monitor
Keyboard Assembly/OPIO
Upper/Lower Arm Assembly
•BIF
Figure 8-91 Articulated Arm - Context
LCD Monitor
Articulated Arm - upper section
Articulated Arm - locking lever
Articulated Arm - lower section
Top aperture
Lower
Aperture
