IRECTION FR091521, REVISION 1 VIVID S60N/VIVID S70N BASIC SERVICE MANUAL
Chapter 8 - Replacement Procedures 8-47
PRELIMINARY
8-3-6-5 Operator Panel Keyboard Assembly Installation Procedure
1) Working from the front of the system, make sure the console is raised to the maximum up position.
2) Make sure that the console is aligned in the central position (not pulled to one side or the other).
3) Follow the steps for the Keyboard Assembly Removal procedure in reverse order, as described in
the Operator Panel Keyboard Assembly Removal Procedure on page 8 - 44.
4) If used, return the basket to the keyboard interface column (refer to OPIO Basket Installation
Procedure on page 8 - 26).
