5-4 Section 5-3 - Vivid™ S60/Vivid™ S70 System Design
PRELIMINARY
Section 5-3
Vivid™ S60/Vivid™ S70 System Design
The design of the Vivid™ S60/Vivid™ S70 ultrasound scanner comprises three main sections
(illustrated in Figure 5-2):
• User Interface
• Main Scanner
• Power Supply - also named the AC Distribution Box
Figure 5-2 Vivid™ S60/Vivid™ S70 Ultrasound Scanner - System Design
Main Display
Touch Screen
Distribution Panel (BIF)
Patient I/O
(ECG and Respiratory)
AC Distribution Box
and Battery
Scanner Electronic Cage
B/W Printer
DVD R/W
Operator Panel
User Interface Section
Main Scanner Section
Power Supply Section
