GE Vivid S60N - Covers - Replacement Procedures; Overview of Covers

D
IRECTION FR091521, REVISION 1 VIVID S60N/VIVID S70N BASIC SERVICE MANUAL
Chapter 8 - Replacement Procedures 8-5
PRELIMINARY
Section 8-2
Covers - Replacement Procedures
8-2-1 Overview of Covers
Figure 8-1 Vivid™ S60/Vivid™ S70 Ultrasound Unit
Table 8-2 Vivid™ S60/Vivid™ S70 Ultrasound Unit Covers (Figure 8-1)
Label Item Label Item
1 Air Inlet (Left Side) Cover 5 Right Rear Cover
2 Right Side Cover 6 AC Box Cover
3 Front Cover 7 DVD Cover
4 Left Rear Cover 8 DVD and Printer Cover
Front View
Rear View
3
1
6
4
7
2
5
8
