D
IRECTION FR091521, REVISION 1 VIVID S60N/VIVID S70N BASIC SERVICE MANUAL
8-158 Section 8-6 - Mechanical Platform Components - Replacement Procedures
PRELIMINARY
8-6-8 Rear Handle Replacement Procedure
NOTE: When replacing a rear handle, make sure the rear handle kit has been ordered, the contents of which
are listed in Table 8-3, below.
8-6-8-1 Tools
Allen Key 2mm
8-6-8-2 Time Required
20 min
8-6-8-3 Preparation
Shut down the Vivid™ S60/Vivid™ S70 ultrasound unit, as described in Power Shut Down on page 4 - 7.
8-6-8-4 Rear Handle Removal Procedure
NOTE: The rear handles are secured to the aluminum bars with a mounting screw and a small amount of glue.
The screw is first released, then a twisting of the handles is required to release the glue before sliding
the handle off the aluminum bar. See the instructions below.
1.) Usin
g the Socket Set Screw Flat Point, loosen and remove the mounting screw from one of the rear
handle.
2.) Gently twist the handle to release the glue, then remove the handle from the aluminum bar.
3.) Repeat step 1 and step 2 to remove the second handle.
Table 8-3 Rear Handle Kit - PN S2424091
P/N Description Quantity
R2421749
Left handle
1
R2420760
Right Handle
1
RD9130410
Socket Set Screw Flat Point M4, L10, DIN 913
1
2419072
Package (White Mantle 260X236X63)
1
2418493
Good for stock Label
1
FRU Part #
Refer to Table 9-7 on page 9-6.
