D
IRECTION FR091521, REVISION 1 VIVID S60N/VIVID S70N BASIC SERVICE MANUAL
3-34 Section 3-6 - Configuration
PRELIMINARY
3-6-4 Optional Peripherals/Peripheral Connection
3-6-4-1 Contents in this Sub-section
Approved Internal Peripherals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-34
Approved External Peripherals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-34
External Peripherals for Connection to USB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-34
External Peripherals for Connection to Ethernet (TCP/IP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-34
3-6-4-2 Approved Internal Peripherals
This list covers the internal peripherals available for Vivid™ S60/Vivid™ S70:
• Monochrome (Black and White) Digital Sony UP_D898 printer
3-6-4-3 Approved External Peripherals
One of the external units listed below, may be connected to the USB port on the rear of the
Vivid™ S60/Vivid™ S70:
3-6-4-4 External Peripherals for Connection to USB
• Footswitch
• Configuration of the footswitch is done on the Config > Imaging > Application screen.
• For more information, refer to the Vivid™ S60/Vivid™ S70 User Manual.
• External Data Storage:
• USB Flash Card
• COLOR Printers:
• SONY UPD-25MD
3-6-4-5 External Peripherals for Connection to Ethernet (TCP/IP)
Related information:
• Optional Peripherals on page 9 - 24
3-6-4-5-1 Connecting the HP Laserjet M451 Color Printer
Figure 3-27 HP Laserjet M451 Color Printer
