D
IRECTION FR091521, REVISION 1 VIVID S60N/VIVID S70N BASIC SERVICE MANUAL
Chapter 8 - Replacement Procedures 8-33
PRELIMINARY
8-3-1-5 Install the 21.5" Monitor
1.) Working from the front of the system, make sure the console is in the maximum down position and
that it is aligned in the central position (not pulled to one side or the other).
2.) Place the monitor in the face-down position.
3.) Using two hands, position the monitor beneath the securing bracket, carefully aligning the two
captive screws with the two key-hole slot openings.
4.) Pull the monitor towards you until the captive screws are correctly positioned while supporting the
monitor from below with one hand, tighten the two screws with torque 1.3Nm.
5.) Return the two securing screws to the securing bracket and fasten with torque 1.3Nm.
6.) Secure the two ground cables.
7.) Plug in the Power cable, the USB cable and the HDMI cable. Refit the P clamp and the screws for
all cables, including the P clamp in the middle of the screen.
8.) Install the Monitor’s Rear Cover, and fasten it with the two screws with torque 1,3 Nm.
NOTE: When positioning the cover, make sure underlying cables are properly seated and will not become
pinched or damaged by the cover.
