IRECTION FR091521, REVISION 1 VIVID S60N/VIVID S70N BASIC SERVICE MANUAL
8-98 Section 8-5 - Electronic Cage Components - Replacement Procedures
PRELIMINARY
8-5-5 BIOS Battery Replacement
NOTE: Since the BIOS battery is not available as a spare part (due to shelf life), it should be obtained locally.
The battery model is CR2032.
8-5-5-1 Tools
Use the appropriate Phillips screwdriver.
8-5-5-2 Time Required
1 min
8-5-5-3 Preparations
Shut down the Vivid™ S60/Vivid™ S70 ultrasound unit, as described in Power Shut Down on page 4 - 7.
8-5-5-4 BIOS Battery Removal Procedure
1) Remove the BEP:
2) Place the BEP on a clean, secure surface.
Note: The location of the BIOS battery in the BEP is shown in Figure 8-122.
BEFORE REMOVING THE BEP, REMEMBER TO PERFORM A FULL INCREMENTAL BACK-UP OF
THE ARCHIVE AND USER PRESETS.
For details, refer to the Operating System and/or Application Software Loading Procedures on
page 8 - 173.
• BEP Removal Procedure on page 8 - 94
Figure 8-122 Location of BEP BIOS Battery
