D
IRECTION FR091521, REVISION 1 VIVID S60N/VIVID S70N BASIC SERVICE MANUAL
Chapter 7 - Diagnostics/Troubleshooting 7-5
PRELIMINARY
Section 7-4
Screen Captures
7-4-1 Purpose of this Section
To capture screen images that can be used for diagnostic and troubleshooting purposes.
7-4-2 Contents in this Section
• Ctrl+PrintScreen Shortcut on page 7 - 5
• Capture a Screen Image Using the Shortcut on page 7 - 5
7-4-3 Ctrl+PrintScreen Shortcut
A Ctrl+PrintScreen shortcut is available for quickly capturing the image displayed on the system.
Images captured using this shortcut are saved in the D:\export directory using both the JPEG (.jpg) and
raw DICOM (.dcm) formats.
The InSite connection will have access to the export folder on the “D:” drive to retrieve these images.
This feature will allow the customer to quickly and easily acquire images that can then be viewed by the
Online Centre (OLC).
7-4-4 Capture a Screen Image Using the Shortcut
Follow the steps in this procedure to capture a screen image:
1) With the desired image displayed on the screen, press Ctrl and PrtSc (print screen) keys
simultaneously.
2) From the touch panel, select: Utility > Service > Utilities > Common Utilities > Image Compress
& Delete Utilities.
3) Select the check box for the image(s) you want to save in the D:\export directory.
4) Select Compress Files.
A compressed file of the images is stored in D:\export. You may rely on the date and time of the
Ctrl+PrtSc procedure to identify the most recent image recorded.
The uncompressed files are stored in: d:\export\service\image.
