GE Vivid S60N - Ecg;Respiratory Module Assembly Replacement Procedure; Tools; Time Required; Preparation

D
IRECTION FR091521, REVISION 1 VIVID S60N/VIVID S70N BASIC SERVICE MANUAL
8-106 Section 8-5 - Electronic Cage Components - Replacement Procedures
PRELIMINARY
8-5-9 ECG/Respiratory Module Assembly Replacement Procedure
8-5-9-1 Tools
Appropriate Phillips screwdriver.
8-5-9-2 Time Required
10 mins
8-5-9-3 Preparation
Shut down the Vivid™ S60/Vivid™ S70 ultrasound unit, as described in Power Shut Down on page 4 - 7.
8-5-9-4 ECG/Respiratory Module Assembly Removal Procedure
1) Remove the following covers: left side, right side, DVD, front.
2) Open the Front End door assembly, as follows:
a.) Open the two fastening latches on the side of the Front End door assembly and carefully open
the cage door.
b.) Secure the cage door with the cage door securing arm - see Figure 8-105 on page 8-84.
NOTE: The location of the ECG/Respiratory Module Assembly is shown in Figure 8-130.
CAUTION
When performing these procedures, take precautions to avoid damage of
electrostatic-sensitive components. Always have the ESD wrist strap
connected either to the DIB chassis or to the GND plug at the rear of the
scanner, and to your hand.
If a battery is present, first remove the battery as it contains stored energy.
Refer to Battery Removal Procedure on page 8 - 145.
FRU Part #
Refer to Table 9-18 on page 9-17.
• Air Inlet (Left Side) Cover Removal Procedure on page 8 - 7
• Right Side Cover Removal Procedure on page 8 - 10
• DVD Cover Removal Procedure on page 8 - 11
• Front Cover Removal Procedure on page 8 - 16
