D
IRECTION FR091521, REVISION 1 VIVID S60N/VIVID S70N BASIC SERVICE MANUAL
Chapter 8 - Replacement Procedures 8-103
PRELIMINARY
2) Unscrew the Plastic Axis Holders’ securing screws and remove the respective axis holders - see
Figure 8-128.
8-5-7-5 Plastic Axis Holders for BEP Installation Procedure
1.) Install the new plastic axis holders in the reverse order as described in the removal procedure
above.
2.) Reinstall the BEP:
3.) Turn ON the system and boot-up.
Figure 8-128 Left and Right Axis Holders
• BEP Installation Procedure on page 8 - 97
Left axis holder
Right axis holder
To Next Page
