IRECTION FR091521, REVISION 1 VIVID S60N/VIVID S70N BASIC SERVICE MANUAL
Chapter 8 - Replacement Procedures 8-137
PRELIMINARY
8-5-19-5 Fan for Cabinet Cage Assembly Installation Procedure
1) Position the replacement fan in the correct location on the cabinet cage assembly.
2.) Fasten the two securing screws as indicated in Figure 8-165.
3.) Reconnect the Fan cable as indicated in Figure 8-165.
4.) Refit the following covers: right rear, front, DVD, right side
5.) Turn ON power to the system.
• Right Rear Cover Installation Procedure on page 8-22
• Front Cover Installation Procedure on page 8 - 19
• DVD Cover Installation Procedure on page 8 - 12
• Right Side Cover Installation Procedure on page 8 - 10
