LCR-8000 Series User Manual
122
The HF LOAD correction is not necessarily
performed. Please refer to the test fixture using
the operating manual and correct it according to
the conditions.
7. Connect the STD-LOAD to the test fixture, and
then perform HF LOAD correction.
The SPOT LOAD correction is not necessarily
performed. Please refer to the correction status
and determine whether to perform SPOT LOAD
correction.
The test fixture correction includes OPEN,
SHORT, HF LOAD, SPOT LOAD Four types
correction processes to obtain compensation data,
but not all of them need to be performed during
correction.
Four types correction procedures can be
independently turned off or turned on to
compensate data for measurement.
For normal measurement, it is recommended to
perform the OPEN correction and SHORT
correction of the test fixture.
For the conditions and methods of test fixture
correction, please refer to the instruction manual
of the test fixture.
To Next Page
