LCR-8000 Series User Manual
12
Characteristics
Thank you for using LCR-8200 SERIES LCR Meter as your testing
instrument. This Manual contains the detailed installation steps. To
ensure personnel safety and to protect your equipment and data,
please check if the following accessories are fully supplied before
starting the installation.
The test frequency of the LCR-8200 SERIES LCR Meter is DC 10Hz-
30MHz and the test signal is 10mV-2Vrms and is suitable for the
LCR and DCR testes of AC signals. The measurement in a
continuously changing environment can be executed stage-by-stage
with the test frequency and grade, and high-speed continuous tests
can be performed under different test and mode conditions. The
machine also supports RS-232, USB, LAN and GPIB PC connection
capabilities to improve the design and test efficiency significantly.
The performance, convenience and operation flexibility of the LCR
Meter have become indispensable tools for the professional
measuring technicians.
Such meter can meet customer demands for price, speed, capacity,
accuracy and multi-function by its well-based flexibility in
combination and implementation. Therefore, it can be used in the
testing of a variety of components such as resister, capacitor,
inductor, oscillator, sensor, time-delay wire, filter and resonator.
Signal source frequency range: DC, 10Hz ~
5/10/20/30MHz
Basic accuracy up to ±0.08%
Signal source grade: 10mV ~ 2V / 100μA ~
20mA
ALC function
Output resistance 25Ω/100Ω, switchable
Parameters: |Z|, |Y|, θ, R, X, G, B, L, C, D, Q,
DCR, ESR, Vac, Iac, Vdc, Idc, etc.
Ultra-high measuring speed
