LIST (MULTI STEP MODE)
93
Setting DC bias
DC BIAS range is -12V~+12V. When input is above the instrument
voltage range will be displayed “Out of range!”. The test step has DC
BIAS. When this step is tested, the instrument will automatically
execute the DC BIAS output, and the DC Bias button will light up and
will automatically turn off at the end of the step.
1. Press the Measure button to enter
[MEAS DISPLAY] page, and then
press the LIST SET function button
on the right side of the LCD to enter
the [LIST SET] page.
2. Use arrow keys to move cursor and
select DC BIAS item on the [LIST
SET] page.
3. Use the numeric keypad to enter the test DC
Bias.
