CORRECTION (OPEN/SHORT)
121
Correction process
Prior to each measurement, the user needs to correction the fixture
or test cable to eliminate stray capacitance and series impedance
that may be generated by the fixture or test cable. Application
when using LCR-8200 or changing a fixture in a new environment.
Please check the test unit and the test fixture used for correct
correction.
The same correction parameters are used for meter mode and
sweep mode and list mode.
1. Go to the CORR. Correction page.
2. Select the type of fixture used for FIXTURN
COMPENSATION item.
3. If the test fixture has a test cable or use an
extension cable, set the CBALE LENGTH
length selection.
After setting FIXTURE COMPENSATION,
CABLE LENGTH will not be set. If you want to
set CABLE LENGTH, you must first set FIXTURE
COMPENSATION to OFF.
4. Set the fixture to the open state, and then
perform OPEN correction.
5. Set the fixture to the short state, and then
perform SHORT correction.
6. Connect the STD-LOAD to the test fixture, and
then perform HF LOAD correction.
To Next Page
