GW Instek LCR Series User Manual

LCR-8000 Series User Manual
150
Universal terminal
Pin#
Name
Logic
Description
1
/EXT_TRIG
I
Negative,
Edge
External trigger signal, pulse
width ≥ 100μs
2
/EOM
O
Negative,
Level
‘’End of all measurement’’
signal
3
/PASS
O
Negative,
Level
Pass signal of comparator
4
/FAIL
O
Negative,
Level
Fail signal of comparator
5
Trig Return
Signal
Return
External Trigger Signal Return
6
COM
Common
ground
Common ground of result
signal
7
COM
Common
ground
Common ground of result
signal
8
--
--
9
--
--
10
+5V out
O
DC_Powe
r Out
+5V Supply, 100 mA max
11
--
--
12
--
--
14
/Ready
O
Negative,
Level
‘’Ready for trigger’’ signal
15
/Index
O
Negative,
Level
‘’End of analog measurement’’
signal
