GW Instek LCR Series User Manual

REMOTE CONTROL
151
Meter mode (BIN off) terminal
Pin#
Name
Logic
Description
16
/PARA-1OK
O
Negative,
Level
Comparator result
17
/PARA-2OK
O
Negative,
Level
Comparator result
18
/PARA-3OK
O
Negative,
Level
Comparator result
19
/PARA-4OK
O
Negative,
Level
Comparator result
20
/PARA-1NG
O
Negative,
Level
Comparator result
21
/PARA-2NG
O
Negative,
Level
Comparator result
22
/PARA-3NG
O
Negative,
Level
Comparator result
23
/PARA-4NG
O
Negative,
Level
Comparator result
24
--
--
25
--
--
List mode (BIN off) terminal
Pin#
Name
Logic
Description
16
/STEP-1OK
O
Negative,
Level
Comparator result
17
/STEP-2OK
O
Negative,
Level
Comparator result
18
/STEP-3OK
O
Negative,
Level
Comparator result
19
/STEP-4OK
O
Negative,
Level
Comparator result
20
/STEP-1NG
O
Negative,
Comparator result
