GW Instek LCR Series User Manual

SWEEP (GRAPH MODE)
73
Setting para
Select test parameters of trace A or trace B.
Steps
1. Press the Measure button to enter
[MEAS DISPLAY] page, and then
press the SWEEP function button on
the right side of the LCD to enter the
[SWEEP DISPLAY] page.
2. Use arrow keys to move the cursor
and select PARA item on the [SWEEP
DISPLAY] page.
3. Use option key on the right of the LCD screen
to select a parameter for this sweep item.
