LCR-8000 Series User Manual
30
Setting trigger mode
LCR-8200 Series offers REPEAT and SINGLE mode.
1. Press the Setup button to enter [MEAS
SETUP] page.
2. Use arrow keys to move cursor and select
TRIGGER item on the [MEAS SETUP]
page.
3. Use option key on the right of the LCD screen to
select a trigger mode for this measurement item.
Internal trigger mode is also known as
continuous test. The trigger signal
performs continuous test in accordance
with the SPEED setting.
Press the Trigger button to pause the
trigger to stop the measurement and
display the “TRIG HOLD” message on
the top of the LCD.
Again press the Trigger button to resume
continuous triggering.
External trigger mode, including
Manual/Handler/TRIGGER
Input/Remote control mode.
