LCR-8000 Series User Manual
224
Average
1 to 64
V/I Monitor
Vac, Iac, Vdc, Idc
File Storage
Meter: 99 sets, List: 48 sets
Comparator
Value, △, △%
Handler
PASS, FAIL and OK, NG or BIN 1-9
Buzzer
OFF, Pass, Fail
Trigger
REPEAT, SINGLE
Interface
USB/GPIB/LAN/RS-232/Handler/USB
Host/TRIGGER Input
Programming
language
SCPI
Specifications
Frequency
LCR-8230
DC, 10Hz~30MHz
LCR-8220
DC, 10Hz~20MHz
LCR-8210
DC, 10Hz~10MHz
LCR-8205
DC, 10Hz~5MHz
Accuracy
0.0007%±0.1Hz
Range and Resolution
Range
Resolution
10.0000 ~ 99.9000Hz
0.1Hz
100.000 ~ 999.900Hz
0.1Hz
1.00000k ~ 9.99995kHz
0.05Hz
10.0000k ~ 99.9999kHz
0.1Hz
100.000k ~ 999.999kHz
1Hz
1.00000M ~ 9.99999MHz
10Hz
10.0000M ~ 30.0000MHz
100Hz
Display Range
lZl
0.000mΩ
to 9999.99MΩ
R,X
±
0.000mΩ
to 9999.99MΩ
Cs, Cp
±
0.00000pF
to 9999.99F
Ls, Lp
±
0.00
nH to 9999.99kH
Q
±
0.00
to 9999.99
D
±
0.00000
to 9999.99
lYl
0.00000
μS to 999.999kS
