GW Instek LCR Series User Manual

APPENDIX
223
Specifications
Below are the basic conditions required to operate the LCR-8200
series within specifications.
 Calibration: Yearly
 Reset adjustment: Perform correction before testing
 The specifications Apply when it warmed up for at least 60
minutes.
General Specifications
Specification Conditions:
Temperature: 18˚C~28˚C
Humidity:  70%RH(non-condensing)
Operating Environment
Temperature Range: 5~40˚C
Relative Humidity:  80%RH(non-condensing)
Storage Conditions
Temperature Range: -10~70˚C
Relative Humidity:  80%RH(non-condensing)
General
Power Consumption: AC 100V~240V, 50/60Hz, Max65VA
Fuse: 250V 3A slow melting
Dimensions: 346 mm (W) X 145 mm (H) X 335 mm (D)
Weight: Approximately 3.3 kg
Display
7" LCD color display (800x480)
Range
Auto range, Hold range
Output
Impedance(RO)
100/25Ω (25Ω:1Vac max)
Auto Level
Control(ALC)
Standard
DC Bias
±12V
Correction
Open/Short/HF Load/Load
Sweep Parameters
Freq/Vac/Iac, Keep Trace
List Parameters
Freq/Vac/Iac/DC Bias/Comp/BIN, Auto Trigger
