HEIDENHAIN TNC 620 Programming Station

Tables and overviews | System data
Group
name
Group number
ID...
System data
number NO....
Index IDX... Description
Values for LAC and VSC
0 Index of the NC axis for which the LAC
weighing run will be performed or was last
performed (X to W = 1 to 9)
0
2 Total inertia determined by the LAC weighing
run in [kgm
2
] (with A/B/C rotary axes) or total
mass in [kg] (with X/Y/Z linear axes)
71
1 0 Cycle 957 Retraction from thread
Freely available memory area for OEM cycles
72 0-39 0 to 30 Freely available memory area for OEM cycles.
The values are only reset by the control during
a control reboot (= 0).
With “Cancel,” the values are not reset to the
value that they had at the time of execution.
Up to and including 597110-11: only NR 0-9
and IDX 0-9
Starting with 597110-12: NR 0-39 and IDX
0-30
Freely available memory area for user cycles
73 0-39 0 to 30 Freely available memory area for user cycles
The values are only reset by the control during
a control reboot (= 0).
With “Cancel,” the values are not reset to the
value that they had at the time of execution.
Up to and including 597110-11: only NR 0-9
and IDX 0-9
Starting with 597110-12: NR 0-39 and IDX
0-30
Read minimum and maximum spindle speed
1 Spindle ID Minimum spindle speed of the lowest gear
stage. If no gear stages are configured,
CfgFeedLimits/minFeed of the first parameter
set of the spindle is evaluated.
Index 99 = active spindle
90
2 Spindle ID Maximum spindle speed from the highest
gear stage. If no gear stages are configured,
CfgFeedLimits/maxFeed of the first parame-
ter set of the spindle is evaluated.
Index 99 = active spindle
Tool compensation
200 1 1 = without
oversize 2 =
with oversize 3
= with oversize
Active radius
15
