HEIDENHAIN TNC 620 Programming Station

Tables and overviews | System data
15
Group
name
Group number
ID...
System data
number NO....
Index IDX... Description
and oversize
from TOOL
CALL
2 1 = without
oversize 2 =
with oversize 3
= with oversize
and oversize
from TOOL
CALL
Active length
3 1 = without
oversize 2 =
with oversize 3
= with oversize
and oversize
from TOOL
CALL
Rounding radius R2
6 Tool no. Tool length
Index 0= active tool
Coordinate transformations
1 - Basic rotation (manual)
2 - Programmed rotation
3 - Active mirror axis. Bits 0 to 2 and 6 to 8:
Axes X, Y, Z and U, V, W
4 Axis Active scaling factor
Index: 1 - 9 (X, Y, Z, A, B, C, U, V, W)
5 Rotary axis 3D-ROT
Index: 1 - 3 (A, B, C)
6 - Tilt working plane in Program Run operating
modes
0 = Not active
–1 = Active
7 - Tilt working plane in Manual operating modes
0 = Not active
–1 = Active
8 QL parameter
no.
Angle of misalignment between spindle and
tilted coordinate system.
Projects the angle specified in the QL parame-
ter from the input coordinate system to the
tool coordinate system. If IDX is omitted, the
angle 0 is used for projection.
210
10 - Type of definition of the active tilt:
0 = no tilt—is returned if, both in Manual
Operation and in the automatic modes, no tilt
is active.
1 = axial
2 = spatial angle
560
