Hioki 3166 - FD Auto Output

82
────────────────────────────────────────────────────
6.5 Changing Settings
────────────────────────────────────────────────────
6
.5.7 FD Auto Output
FD Auto Output Setting
NOTE
Select "ON" in order to save measurement data to floppy disk automatically.
The time interval at which the data is automatically saved is the time set for
the "Output interval."
Options: ON/OFF
* OFF
Example With an FDD UNIT connected, automatically saving measurement data on
a floppy disk
Position the cursor at "FD auto output(FD AUTO SAVE)."
Press the ON function key.
"ON" is displayed and set in the "FD auto output" field.
・When set to "ON", the optional 9595 FDD Unit must already be connected to
the 3166.
・If additional integration is performed when this setting is "YES", all data is
saved to the same file.
