Hioki 3166 - File Names; RS-232 C Automatic Output

83
────────────────────────────────────────────────────
6.5 Changing Settings
────────────────────────────────────────────────────
6
.5.8 File Names
File Name Setting
NOTE
6
.5.9 RS-232C Automatic Output
NOTE
This sets the file name when measurement data is being saved to floppy disk.
The file name, the date and time at which measurement started, the
measurement data itself, and the date and time at which the measurement
data was saved are all saved on the floppy disk.
Setting range: Up to eight normal-width characters (alphanumerics, katakana)
or four double-width characters (kanji, hiragana, katakana).
* No file name is set when the power meter is shipped from the
factory.
For details on the specific method for setting the file name, refer to section
5.5.2, "File Names."
Select "ON" in order to print out measurement data automatically. The time
interval at which the data is automatically printed is the time set for the
"Output interval time."
Options: ON/OFF
* OFF
Example With a printer connected, automatically printing measurement data
Position the cursor at "RS-232C auto output (RS-232C AUTO OUT)."
Press the ON function key.
"ON" is displayed and set in the "RS-232C auto output" field.
When set to "ON", the printer must already be connected to the 3166. In
addition, the setting for the device connected to the "RS-232C interface" must
be "PRINTER" (refer to section 8.2.11, "RS-232C Device.")
