8.3 Printing Out the Settings
────────────────────────────────────────────────────
NOTE
8
.3 Printing Out the Settings
Pressing the PRINT key while either page 1 or page 2 of the "Function
Settings" screen is displayed causes all of the current power meter settings to
be printed out.
In addition to the items that were set in "Setting" mode, the special settings
that were set for each measurement mode are also printed out.
This function can also be executed in the same manner from the setting
screens for each measurement mode.
・Before printing, be sure to set the printer as the device connected to the RS-
232C interface, and connect the printer to the power meter’s RS-232C
connector. (Refer to section 8.2.11, "RS-232C Device.")
・If the printer is not set as the device connected to the RS-232C interface,
nothing happens when the PRINT key is pressed.
