Hioki 3166 - Chapter 7 Demand Measurement; Capabilities in Demand Measurement Mode

89
────────────────────────────────────────────────────
7.1 Capabilities in Demand Measurement Mode
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
Chapter
7
Demand Measureme
nt
7
.1 Capabilities in Demand Measurement Mode
In "Demand Measurement" mode, in addition to being able to take the same
measurements as are available in "Integrated Measurement" mode, it is also
possible to perform demand measurements in which integrated measurements
are repeated at a time interval that is ideal for power management.
This chapter explains the necessary settings for demand measurement, how to
display various measured values, and how to save data to floppy disk or print
it on the printer.
Reference When using "Demand Measurement" mode, the "Normal Measurement" and
"Integrated Measurement" mode measurements are also included.
The following measurement display functions and data processing functions
can be used in Demand Measurement mode.
●Display (Refer to section 18.3, "Measurement Items and Calculations"
for details on the items that are displayed.)
(1) Instantaneous value display
(2) Integrated value display
1. Integrated value display screen (page 1/2) (displays power integration
consumption average value, and maximum demand value)
2. Integrated value display screen (page 2/2) (displays details about power
integration, such as power consumption/regeneration)
3. Instantaneous Value Minimum/Maximum screen (values during the
integration period)
