Hioki 3166 - Wiring Settings and Wiring Methods

33
────────────────────────────────────────────────────
4.4 Wiring Settings and Wiring Methods
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
Check Window
Wiring Diagram Display
(Single-phase, Two-wire)
Re
d
Blac
k
Loa
d
Power
supply
1
N
Wiring Diagram (Single-phase, Two-wire)
3. Position the cursor on "Move to Wiring."
4. Press the
EXEC. function key.
5. The "Wiring Check" screen is displayed.
The wiring settings and the wiring diagram are displayed on the screen.
