Hioki 3166 - Setting a Modem Connected to a Personal Computer

245
────────────────────────────────────────────────────
12.2 Functions That Use the Modem (1)
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
1
0
1
1
1
2
1
3
1
4
A
NOTE
1
2.2.4 Setting a Modem Connected to a Personal Computer
・When it is necessary to use "\" (backslash) character, instead of the character
that can be used "￥" normal-width.
・When it is necessary to dial zero first to call from an extension, try adding a
zero at the start of the destination number. Also set the modem initialization
command to "ATTQ1X0&C1&D2" (when using tone dialing).
(5) Setting the ID code
The character string set for this item is sent together with the data when data
is sent from the modem. Any character string can be set.
It is necessary to set "Auto Answer" for a modem that is connected to a
personal computer. An example of the procedure for doing so is described
below.
(1) Connect the modem to the personal computer with a straight cable.
(2) Turn on the modem and start up the personal computer.
(3) Start up the terminal (communications) software.
(4) Input the following from the personal computer terminal:
ATZ[Enter]
If "OK" is displayed, the modem is connected correctly.
(5) Input:
ATS0=1[Enter]
"OK" is displayed.
The modem is now ready for automatic output of measurement data.
In Integrated Measurement mode and Demand Measurement mode, set either
the interval period or the demand period, and then set "RS-232C automatic
output." Once measurement begins, the 3166 automatically sends the data
through the modem at the output time. The personal computer receives this
data automatically and displays it.
