.2.1 Reactive Power Meter Method
NOTE
8
.2 Settings for Each Item
The asterisk ("*") is used in this section to indicate initial values (initial
settings when the power meter is shipped from the factory).
●Selecting the setting mode
1. Position the cursor at "Setting" on the initial screen. For the details on the
initial screen, refer to section 2.3, "Initial Screen."
2. Press the
EXEC. function key
3. The "Function Settings" screen (page 1/2) is displayed.
The settings are organized on two screens, use the
NEXT and PREVIOUS
function keys to switch between the screens.
Once all of the settings have been made, press the
RET. function key in order
to return to the initial screen.
The
RET. function key can even be pressed in order to return to the initial
screen before all of the settings have been made.
If the
RET. key is pressed while integrated measurement or demand
measurement is in progress or after integrated measurement or demand
measurement is complete, a message is displayed and the display does not
return to the initial screen. Terminate integrated measurement or demand
measurement and press the DATA RESET key before pressing the RET. key.
The message disappears when any of these keys is pressed.
●Items that can be changed when the "Function Settings" screen
(page 1/2) is displayed
This item sets whether or not to use the reactive power meter method for
calculating the reactive power measurements.
Options: Use reactive power meter method: YES/NO
*NO
Example Using the reactive power method
Position the cursor at "Reactive power method (REACTIVE POWER
METHOD)" item.
Press the YES function key.
"YES" is set and is displayed in the "Reactive power method" field.
The measured value is measured directly with a reactive power meter, and
then the reactive power is calculated. In addition, "Power ratio power factor"
displays the power factor when using the reactive power meter method.
Refer to item 3 in the Appendices for a supplementary explanation.
