Hioki 3166 - Chapter 4 Wiring Methods; Before Measurement

29
────────────────────────────────────────────────────
4.1 Before Measurement
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
DANGE
R
This unit cannot be used on voltage lines of 600 Vrms. If the voltage
exceeds 600 VAC, there will be a short-circuit accident or electrocution
accident will result.
CAUTIO
N
・Avoid stepping on or pinching the cable, which could damage the cable
insulation.
・To prevent damage to the product and sensor, never connect or disconnect
a sensor while the power is on.
Chapter
4
Wiring Method
s
4
.1 Before Measurement
This chapter explains how to wire the power meter to the line being measured,
and how to check for incorrect wiring.
